Processor | Intel Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core up to 4.6GHz, E-core up to 3.4GHz, 12MB Intel® Smart Cache |
AI PC Category | Non-AI PC |
NPU | None |
Graphics | Integrated Intel® UHD Graphics |
Chipset | Intel® SoC Platform |
Memory | 1x 16GB SODIMM DDR5-5200 |
Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
Max Memory | Up to 64GB DDR5-5200 |
Storage | 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
Storage Slot | Two M.2 slots
• One M.2 2242 PCIe® 4.0 x4 slot
• One M.2 2280 PCIe® 4.0 x4 slot |
Max Storage Support | Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 2TB
• M.2 2280 SSD up to 2TB |
Card Reader | SD Card Reader |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audio™ |
Microphone | 2x, Array |
Camera | FHD 1080p + IR Hybrid with Privacy Shutter |
Battery | 48Wh |
Power Adapter | 65W USB-C® (3-pin) |
Special Features | Modern Standby |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC |
Touchscreen | None |
Screen-to-Body Ratio | 90% |
Color Calibration | No Color Calibration |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
Dimensions (WxDxH) | 313.5 x 224 x 17.5 mm (12.34 x 8.82 x 0.69 inches) |
Weight | Starting at 1.36 kg (2.99 lbs) |
Case Color | Arctic Grey |
Case Material | Aluminium (Top), PC-ABS (Bottom) |
Surface Treatment | Anodizing Sandblasting (Top), Texture (Bottom) |
SOFTWARE |
Operating System | None |
Bundled Software | None |
CONNECTIVITY |
WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3 |
WWAN | WWAN Not Supported |
Ethernet | 100/1000M (RJ-45) |
Standard Ports | 1x USB-A (USB 5Gbps), Always On 1x USB-A (USB 5Gbps) 1x USB-C® (USB 10Gbps), with USB PD 45-65W and DisplayPort™ 1.4 1x Thunderbolt™ 4, with USB PD 45-65W and DisplayPort™ 1.4 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x SD card reader
|
Docking | Various docking solutions supported via Thunderbolt™ / USB-C®.
For more compatible docking solutions, please visit Docking for ThinkBook® 14 G9 IRL |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington Nano Security Slot™, 2.5 x 6 mm |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | |
MANAGEABILITY |
System Management | Non-vPro® |
SERVICE |
Base Warranty | 1-year, Courier or Carry-in |
Included Upgrade | 2Y Premier Support Upgrade from 1Y Courier/Carry-in |
